87.5MPa减压阀



87.5MPa减压阀参数

名称

一级减压阀

型号

JYF70-1MPa-0

进口通径

DN3

出口通径

DN12

进口压力

287.5MPa

出口压力

02MPa(可调)

介质

空气、惰性气体、氢气

温度

-40+67


87.5MPa Pressure reducer

Name

First stage pressure reducer

Model

JYF70-1MPa-0

Inlet

DN3

Outlet

DN12

Inlet Pr.

287.5MPa

Outlet Pr.

02MPa (Adjustable)

Medium

Air, inert gas, hydrogen

Temperature

-40+67


介绍:

该阀是活塞式减压阀,适用于自动控制领域,出口压力响应时间快。适用于管路系统中有多种压力。进口设有50μ过滤网。
Introduction:

The valve is piston pressure reducer, suitable for automatic control, outlet pressure response time is fast. It is suitable for many medium pressures in the piping system. The inlet is provided with a 50μ filter.
