DN12电磁阀参数

名称	电磁阀
型号	HTFH-DCF-DN12S(G)
通径	DN12
PN压力	5(25)MPa
电压	21～30Vdc
电流	0.8～1.1A
介质	惰性气体、air
温度	-40～+80℃

DN12 Solenoid valve

Name	Solenoid valve
Model	HTFH-DCF-DN12S(G)
Size	DN12
PN Pressure	5(25)MPa
Voltage	21～30Vdc
Current	0.8～1.1 A
Medium	Inert gas, air
Temperature	-40～+80℃

介绍：

该阀是先导式电磁阀，适用于自动控制领域，响应时间快。在最大压力下，开启时间≤100ms，关闭时间≤80ms。阀由两端M22x1.5螺纹连接，密封为球形接头密封。表中由两种型号，S结尾的开启最高压力5MPa，G结尾的开启最高压力25MPa。
Introduction:

The valve is pilot type solenoid valve, suitable for automatic control, response time is fast. At maximum pressure, pull up time ≤100ms, release time ≤80ms. The valve is connected with M22x1.5 threads at both ends, and the seal is a spherical joint seal. There are two models in the table. The maximum opening pressure is 5MPa at the end of S, and the maximum  opening pressure is 25MPa at the end of G.
