天然气电磁阀参数

名称	电磁阀
型号	HTFH-DCF-T8
通径	DN8
PN压力	21MPa
电压	220～240Vac
电流	16～18mA
介质	CNG（天然气）
温度	-60～+50℃

Natural gas solenoid valve

Name	Solenoid valve
Model	HTFH-DCF-T8
Size	DN8
PN Pressure	21MPa
Voltage	220～240Vac
Current	16～18mA
Medium	CNG（Natural gas）
Temperature	-60～+50℃

介绍：

该阀是先导式电磁阀，适用于自动控制领域，响应时间快。在最大压力下，开启时间≤100ms，关闭时间≤80ms。阀由两端G3/8”管螺纹连接。
Introduction:

The valve is a pilot solenoid valve, suitable for automatic control field, fast response time. At maximum pressure, pull up time ≤100ms，release time ≤80ms. Valves are with G3/8 " pipe thread at both ends.
